Spirit 1.0 Evo Outboard Motor

State-Of-The-Art technology now – light, practical, manageable, ecological and quiet. Perfect motor for your days on the water.

Portable. Powerful. Perfect.

Divider

The ePropulsion Spirit 1.0 EVO is a portable 3HP electric outboard made for dinghies, fishing boats, and sailboats. It features a 1276Wh large integrated lithium battery for long range. The regenerative battery function is great for sustainable sailing experience. The safety wristband keeps you safe in case of MOB. Includes remote steering instead of a tiller. Optional remote control available. The Spirit 1.0 Evo is the first-ever electric outboard that features hydrogeneration. ePropulsion pioneers in the innovation of electric outboard motors and we dedicate ourselves to sustainable sailing. The Spirit 1.0 Evo outboard with battery is portable & easy to transport. It would be a pleasure to have Spirit 1.0 Evo in your gear list when preparing a trip.

Features At a Glance

White Divider
Spirit 1.0 Plus

Performance.

Spirit 1.0 Plus is powerful and can push 3,000 pounds.  It delivers 1 KW or 3HP with constant torque. Direct drive. Maintenance free. Economical and great value. Ecological and keeps our water clean.

Spirit 1.0 Plus

Floats.

Submersible. Outer case is extremely durable and resistant to high heat. Built-in carrying handle. Easy installation in seconds.

Spirit 1.0 Plus

Portable.

Lightweight. Easy to carry.  Convenient, carrying bags are available. Foldable tiller for easy transport.

Specifications

Divider

Spirit 1.0 Evo Performance

Power (Watt)Speed (kmph/knot)Running TimeRange (km/nm)
1255.2/2.810:0052/28
2506.5/3.55:0032.5/17.5
5007.1/3.82:3017.8/9.5
7508/4.31:4013.3/7.2
10009/4.91:1511.25/6.1

* The performance data is based on a 12-foot aluminum boat with one Spirit battery in calm lake water. Speed, range and running time may vary due to external conditions.

Spirit 1.0 Evo Specs

Power1kW / 3HP
Battery Capacity1276 wH
Motor Weight*11.3 kg / 24.9 lbs
Battery Weight8.7 kg / 19.2 lbs
Battery Life800 cycles at 80% DOD
Shaft LengthShort: 24.6 inches, Long: 29.5 inches
Trim / Tilt Angle0°, 7°, 14°, 21° / 85°
Propeller11″ × 5.8″ 2-blade composite propeller

* The weight is measured with the short shaft version

Spirit Battery: Taking You Further

White Divider

Floating Battery

Removing your battery to take it to and from your boat could mean accidentally dropping it in the water. That’s why we developed the Spirit battery to float! You will never lose a battery overboard again.

Solar Charging

Using a solar panel, you can charge your battery up to 180 W while in use. On a sunny day, your battery could last all day if used at the economical power level. An additional benefit is that the solar panel is lightweight and foldable. An additional solar charger is required for this functionality.

Effortless Battery Replacement

To extend the range even further, you can purchase an additional Spirit battery.  The battery is secured by a pull latch and changing out your battery usually takes less than 30 seconds. The process is very easy and it is good to know that storing your Spirit battery is safer than other fuels such as petrol/gasoline.

One Charge to Go 22 Miles

Seattle

Seattle

Pike Place Market to Golden Gardens Park
Round Trip  ⁄  18 Miles

Miami

Miami

Miami Seaquarium to North Beach
Round Trip  ⁄  17.6 Miles

San Francisco

San Francisco

Golden Gate Bridge to Alcatraz Island to Pier 39
Two Laps  ⁄  16 Miles

Safety
